Tubing & casing
January 4, 2019
In recent years, with the decreasing number of easily exploitable oil and gas wells, it has become necessary for oil and gas wells to go deeper on both underground and underwater. And, tubing and casing strings are subjected to higher temperature and higher pressure in these wells, which would probably cause casing failure or gas leakage in the high-pressure/high-temperature (HPHT) wells. Hence, more attention has been paid to wellbore integrity in oil and gas industry in recent years.1,2 The key factor of wellbore integrity is casing string connections, which are expected to provide both structural and leakage integrity under severe environment. […]
May 3, 2018
NOTES: – All threads are to be coated a high – grad thread lubricant conforming to AOI bull 5a2 before fitting with protector – all tube bodies to be coated with external standard mill varnish for protection against rust during transit – third party inspection ( M.P.I on thread ends & full length)will be performed by third party at out site. – API drift full length for all casing except 9 5/8″ casing 53.5 IB/FT will bedrifted by special drift min of 8.5″ OD – API thread guage. U. Price Unit QTY Description NO FT 1040 24″x1″ Thickness conductor […]
May 3, 2018
Product Number: Sumitomo Metal SM 2535 / Tubing 23 Lb/ft / OD: 7″ / ID: 6.366″ / Tubing 26 Lb/ft / OD: 7″ / ID: 6.276″. TECHNICAL SPECIFICATIONS: General Definition of Equipment 1.1 Tubing / Liner 1.1.1.: 28% Cr Material 7” OD tubing, 23, 26 Lb/ft, range II, 100-130 ksi yield strength. Pup joints 0.75 m, 1 m, 1.25 m, 1.5 m, 3 m and 6 m long with the same specification. All thread and coupled with VAM TOP–I or equivalent connections. 1.2 Accessories 1.2.1.: 28% Cr Material 7” coupling All connections with VAM TOP-I or equivalent connections. 7” drift caliper (Teflon material). Pipe dope. […]
April 20, 2018
PSL1 oil casing API 5CT PSL1 tubing product specification range No. Ordering number Specifications Executive standard Outside diameter /mm Wall thickness /mm Economic length /m 1 H40 J55 K55 10 to 127 1 to 20 6 to 12.0 API 5CT PSL2 Oil casing specifications PSL2 42 to 114.3 3.5 to 12 6 to 12.2 114.3 to 180 3.8 to 22 6 to 12.2 68 to 219 10 to 20 6 to 12.2 80 to 219 20 to 30 6 to 12.2 140 to 368 6 to 30 6 to 12.2 318 to 720 14 to 30 6 to 12.5 2 N80-1 N80Q R95 L80-1 C90-1 T95-1 P110 Q125-1 42 to 114.3 3.5 to 12 6 to 12.2 114.3 to 180 3.8 to 22 6 to 12.2 68 to 219 10 to 25 6 to 12.2 140 to 368 6 to 25 6 to 12.2 318 to 720 14 to 25 6 to 12.5 3 L80-1 R95 P110 68 to 219 25 to 35 6 to 12.2 140 to 368 25 to 35 6 to 12.2 318 to 720 25 to 35 6 to 12.5 API 5CT PSL1 Casing Product Specification Range […]
April 6, 2018
油管和套管管道大小的API耦合and Specifications For Tubing and Casing Couplings Descriptions and size End Type O.D*L Weight Descriptions and size End Type O.D*L Weight (mm) (kg) (mm) (kg) Tubing Coupling 1.050 NUE 33.35*80.96 0.23 Casing Coupling 4-1/2″ STC 127.00*158.75 5.23 1.050 EUE 42.16*82.55 0.38 4-1/2″ LTC 127.00*177.80 4.15 1.315 NUE 42.16*82.55 0.38 4-1/2″ BTC 127.00*225.42 4.55 1.315 EUE 48.26*88.90 0.57 5″ STC 141.30*165.10 4.66 1.660 NUE 52.17*88.90 0.59 5″ LTC 141.30*196.85 5.75 1.660 EUE 58.88*95.25 0.68 5″ BTC 141.30*231.78 […]
January 9, 2018
Once a well has been drilled, if it is to become a production well, the well must undergo completion. While drilling a well cuts through the rock formations and allows drilling engineers to reach the reservoir below, the raw sides of the well cannot support themselves. Similar to the bones of your spine protecting the spinal cord, casing is tubing that is set inside the drilled well to protect and support the ABTER STEEL. You can choose the oil casing to use, select the casing size range as follows： Standard: API 5CT Steel Grade: J55, K55, N80, L80, C90, T95, P110, Q125, V150 Dimension: 4 1/2″–20″ Connection: BTC, STC, LTC * P – […]
